The OP9 series is a 5-digit indicator to adjust and to read directly a motion or an angle, obtained by a drive shaft rotation.
The document describes the FIAMA OP 9, a two-digit digital position indicator designed for direct reading of displacement or angle via the rotation of a command shaft. It features an impact-resistant, self-extinguishing technopolymer housing with IP64 protection and can operate up to a maximum temperature of 80°C. This manual is written in Italian.
| Protection Class | IP64 |
|---|---|
| Maximum Temperature | 80°C |
| Digit Count | Two digits (red for tenths/hundredths) |
| Maximum Reading | 99999 |
| Standard Shaft Hole Diameter | 30 H7 |
The maximum operating temperature is 80°C.
Yes, it supports both decimal and inch measurements with a red digit for tenths or hundredths.
