R 5 0025-0100 F Rotary vane vacuum pumps are a new product from the German company Kraftmann. They have the advantages of low ultimate pressure and high suction capacity, especially at an operating pressure of 1 hPa (mbar). This vacuum pump can be used in many industrial applications and is more effective when operating continuously.
This document provides technical data for the Busch R5 series of rotary vane vacuum pumps, specifically models R 5 0025 F, R 5 0040 F, R 5 0063 F, and R 5 0100 F. The pumps feature a rugged design with a direct-drive standard motor and an integrated non-return valve to prevent venting when shut down. They are air-cooled with internal oil recirculation and include a standard oil separator for clean exhaust air.
| Water vapour tolerance max. | 85 °C |
|---|
These pumps work according to the rotary vane principle, where an eccentrically installed rotor rotates in a cylinder, pushing vanes against the wall to separate space into chambers.
The pumps are cooled by air and feature an internal oil recirculation system.
A suction flange with an integrated non-return valve prevents the venting of the vacuum system when the pump is shut down.
