The document is the product manual of the pressure transmitter with model number CB60/CE61. Its features include the measuring range of 0.1 bar to 0.4 bar, the linearity error including hysteresis of less than 0.2%, and the internal diaphragm and surface mounted diaphragm.
This document is a technical datasheet for the Endress+Hauser COMPACT series of pressure transmitters, specifically models CB60 and CE61. These devices are designed for general applications with measuring ranges from 0...1 bar up to 0...400 bar. They utilize a piezoresistive measuring system with internal or flush-mounted diaphragms made of stainless steel.
| Measuring ranges | 0...1 bar up to 0...400 bar |
|---|---|
| Linearity error | <+ 0.2 % f.s. |
| Measuring system | Piezoresistive |
| Output signal | 4...20 mA |
| Process temperature (standard) | -10...+80 °C |
| Process temperature (sterilization) | up to + 140 °C |
| Degree of protection | IP 65 or IP 67 |
| Material (sleeve and diaphragm) | 1.4404 (316L) stainless steel |
| Functional safety classification | SIL 2 |
The device supports a process temperature of up to +140 °C for short-term sterilization.
The CE61 series offers G 1/2 B with flush mounted diaphragm and M22x1.5 with flush mounted diaphragm.
Yes, it has Ex approval according to ATEX intrinsically safe standards (II 2G Ex ib IIC T6).
