AMD SD186ED Demonstration Board User's Manual

The AMD SD186ED Demonstration Board is an exceptionally small, low-cost product for demonstration of the AMD Am186™ED microcontroller.

AMD SD186ED Demonstration Board User's Manual - cover page
Brand
SD186ED
Category
microcontrollers
Document type
User Manual
Language
English
Pages
42
File format
PDF
File size
528 KB
Published
09 July, 2012
Updated
30 September, 2023
MD5 checksum
FE0AE3C002D75FDAEC7DE6E4225418F5
PDF
AMD SD186ED Demonstration Board User's Manual PDF

About this manual

The AMD SD186ED Demonstration Board is a stand-alone evaluation platform designed to demonstrate the features of the Am186ED microcontroller. It serves as a minimal system core for prototyping external devices, featuring an integrated 40-MHz processor, 4 Mbit DRAM, and 4 Mbit Flash memory.

What's inside

  • Quick Start
  • SD186ED Demonstration Board Functional Description
  • Product Support

Frequently asked questions

What software is included on the board?

The SD186ED demonstration board is shipped with the E36MON software installed in the on-board Flash memory.

What are the installation requirements for the PC?

A PC with an available COM port and terminal emulation software supporting ASCII file transfers, flow control, and send break capability.

How many serial ports does the board have?

The demonstration board features two RS-232 serial ports with DB-9 connectors.
