This manual introduces the features and usage of the EasyPIC6 development system, including connecting the system to PC, supported microcontrollers, on-board programmer, mikroICD (Hardware In-Circuit Debugger), power supply, RS-232 communication interface, PS/2 communication interface, ICD connector, USB communication, DS1820 temperature sensor, A/D converter, LEDs, push buttons, rotary switches, LCD display, etc.
The MikroElektronika EasyPIC6 is a full-featured development tool designed for programming and experimenting with PIC microcontrollers. It features an on-board USB 2.0 programmer with mikrolCD support, allowing users to write code in various compilers and load it directly onto the device without external hardware.
The board includes numerous integrated peripherals such as graphic LCD displays (128x64), alphanumeric LCDs (2x16), touch panels, keypads, and a port expander. These modules enable users to easily simulate target devices and test projects in real-time.
| Supported Microcontroller Packages | DIP40, DIP28, DIP20, DIP18, DIP14 and DIP8 |
|---|---|
| Power Supply (External) | 7V to 23V AC or SV to 32V DC |
| Power Supply (USB) | 5V DC |
| Max Power Consumption | up to 40mA |
| Dimensions | 26,5 x 22cm |
The EasyPIC6 provides sockets for PIC microcontrollers in DIP40, DIP28, DIP20, DIP18, DIP14 and DIP8 packages.
Yes, the system can be powered over a USB cable which provides 5V DC.
