The W-DMX system is a wireless solution for larger indoor and outdoor installations, as well as one-off events with long distances. It utilizes advanced wireless technology for reliability and high performance.
The W-DMX BlackBox system is a wireless solution designed for lighting control, offering reliable data transmission over large distances using adaptive frequency hopping and time division multiple access technologies. It adheres to the USITT DMX-512 standard and is engineered to provide the same quality and reliability as hardwired connections while simplifying installation for indoor, outdoor, and temporary events.
The document provides specific instructions for various BlackBox units, including the S-1 and S-2 transmitters, T-1 transceiver, R-512 receivers, and B-500/B-1000 boosters. It details how to link units, manage point-to-point and point-to-multipoint configurations, and utilize the DMX bypass feature for power and data transmission.
| Transceivers on bus (max) | 32 |
|---|---|
| Data rate (max) | 250 kbps |
| AC input voltage | 90-250VAC |
| DC input voltage | 12VDC |
| ESD protection | ±15 kV |
| Output power | 20-25 dBm |
| Frequency range | 2402 to 2479 MHz |
| Sensitivity at 0.1% BER | -95dBm |
A multipoint W-DMX BlackBox system can support up to 512 individual receivers responding to a single transmitter.
Power on the receiver units and press and release the FUNCTION button on the transmitter to scan for unlinked receivers for ten seconds.
All BlackBox products are covered by a standard 12 month full warranty from the purchase date when registered.
