This document describes the features and characteristics of the NS-U40P Natural Sound Satellite Speaker Package.
The Yamaha NS-U40P is a natural sound satellite speaker package designed for home theater systems. The kit includes five identical full-range speakers intended to be configured as two front speakers, one center speaker, and two rear speakers. The manual details the recommended placement strategies to optimize audio performance, including wall mounting options and specific positioning relative to monitors.
| Nominal Input Power | 15W |
|---|---|
| Maximum Input Power | 50W |
| Frequency Response | 120 Hz-25 kHz |
| Dimensions (W x H x D) | 70 mm x 95 mm x 118 mm |
| Weight | 0.3 kg (0.6 lbs.) |
The package includes five full-range satellite speakers.
Yes, the speakers can be hung on a firm wall or wall support using screws and slits on the rear of the speaker.
The center speaker should be placed precisely between the front speakers, or it can be placed on top of a monitor.
If one speaker is connected with reversed polarity, the sound will be unnatural and lack bass.
