The S-805 Series is a family of non-adjusting voltage detectors manufactured using a CMOS process. These devices feature an internally fixed detection voltage composed of a high-precision standard voltage source, a comparator, a hysteresis circuit, and an output driver. The series offers low power consumption with a typical value of 1.4 µA at Vpp = 1.5V.
| Power supply voltage (Vop) | -12.0 V to +12.0 V |
|---|---|
| Operating temperature (Topr) | -20°C to +70°C |
| Storage temperature (Tstg) | -40°C to +125°C |
| Typical current consumption | 1.4 µA (at Vpp = 1.5V) |
The typical power consumption is 1.4 µA when the supply voltage (Vpp) is 1.5 V.
The series offers Nch open-drain and CMOS output forms.
