Yamaha DME Designer Owner's Manual Version 4.0

Owner's manual for DME Designer software and DME audio processors. Explains how to use DME Designer software to build custom audio system installations.

Brand: Yamaha
Document type: User Manual
Language: English
Pages: 526
File format: PDF
File size: 52.1 MB
Published: 11 June, 2012
Updated: 28 September, 2023
MD5 checksum: 0236AC9EF11683BE97B5D16629FCF44E
PDF: Yamaha DME Designer Owner's Manual Version 4.0 PDF

About this manual

The DME Designer software provides a central interface for creating and controlling complex DME-based audio systems. It allows users to design configurations via a block-diagram interface, managing components such as equalizers, mixers, and external device controls. The system supports various applications including audio installations, sub-mixing, speaker control, matrix routing, and multi-effect processing.

What's inside

Getting Started
DME Audio System Network
Software Application Concepts
Data Handled by DME
SP2060 Data Structure
System Configuration
Scene Management

Frequently asked questions

What models does the abbreviation 'DME' refer to in this manual?

The abbreviation DME refers to the DMEG4N, DME24N, DME8i-C, DME80-C, DME4io-C, DMESi-ES, DME8o0-ES, and DME4io-ES.

Can DME units and SP2060 units be combined in the same Device Group?

No, DME and SP2060 units cannot be combined in the same Device Group.
