The document describes the ZSiaS S-29XX0A Series, which are high speed, low power 1K/2K/4K-bit E2PROMs organized as 64-wordx16-bit, 128-wordx16-bit, and 256-word x 16-bit. These devices feature a wide operating voltage range from 1.8V to 6.5V and are compatible with various instruction codes including NM93CSXX and CAT35C102 series.
| Capacity | 1K/2K/4K-bit |
|---|---|
| Organization | 64-wordx16-bit / 128-wordx16-bit / 256-word x 16-bit |
| Endurance | 10^5 cycles/word |
| Data Retention | 10 years |
| Operating Voltage (Read) | 1.8 to 6.5 V |
| Write Voltage Range | 2.5 to 6.5 V |
| Standby Current (Max) | 1.0 pA |
| Operating Temperature | -40 to +85 °C |
The S-29130A is compatible with the NM93CS46 instruction code.
The write operation is completed in a maximum of 10 ms.
