The MC79L00 series is a fixed negative voltage integrated circuit voltage regulator with 3 terminals, output current up to 100mA, no external components required, internal thermal overload protection, internal short circuit current limiting, and can be directly replaced by Motorola MC79L00 series products
The document details the Wing Shing Computer Components Co., (H.K.)Ltd. WS79L00 series of fixed negative-voltage integrated-circuit voltage regulators. These devices are designed for a wide range of applications, including on-card regulation and controlling series pass elements to create high-current circuits.
Key features include an output current capability up to 100 mA, internal thermal-overload protection, and internal short-circuit current limiting. The datasheet provides electrical characteristics, equivalent schematics, absolute maximum ratings, recommended operating conditions, and pad location coordinates for the TO-92 package.
| Output Current | Up to 100 mA |
|---|---|
| Package Type | TO-92 |
| Chip Size | 1.15 x 1.35mm |
One of these regulators can deliver up to 100 mA of output current.
