The Interpoint VPC Series consists of single-ended forward topology DC/DC converters designed with current mode pulse-width modulation. These units feature a wide input voltage range from 20 to 72 VDC and provide output voltages of 3.3V, 5V, 12V, or 15V with up to 45 watts of power.
| Input Voltage Range | 20 to 72 VDC |
|---|---|
| Output Power | Up to 45 watts |
| Efficiency | Up to 81% |
| Output Voltages | 3.3, 5, 12 and 15 VDC |
| Operating Temperature Range (Case) | -40°C to +85°C |
| Isolation Voltage | 700 VDC |
| Switching Frequency | 220 kHz (typical) |
Pin 4 (trim terminal) can be used with either a trim pot or a fixed resistor across the sense terminals to adjust the output voltage.
No, because input and output filtering are built into the converter design.
