The Components Analyzer is a high impedance digital Volt-Ohm meter designed to measure DC Volts (0-20V), pickup coil output, and resistance across five ranges. It features an LCD display with special indications for infinite resistance or low battery status.
This guide details safety precautions for testing vehicle batteries and ignition systems, explains how to disable electronic ignition systems on various makes like GM HEI and Ford, and describes specific tests for fuses, primary ignition voltage, alternators, and coils.
| DC Volts Range | 0-19.99V DC |
|---|---|
| Pickup Coil Output Range | 0-19.9 VP-P |
| Low Ohms Scale | 0-199.9 |
| Hi Ohms Range | 0-1.999K to 0-199.9K |
| Input Impedance | 10 Megohm |
It indicates infinite resistance or an overrange reading.
It means one of the 9 volt analyzer batteries is weak and should be replaced.
The reading should be between 4.5 and 7.5 volts.
