Analog Devices LTC3612 Monolithic Synchronous Step-Down Regulator Datasheet

The document describes the features and characteristics of the LTC3612 monolithic synchronous buck regulator, including high efficiency, adjustable output, and the ability to choose from multiple light load operating modes.

Brand: Linear Technology
Category: Other Electronics
Document type: Datasheet
Language: English
Pages: 3
File format: PDF
File size: 564 KB
Published: 05 June, 2012
Updated: 29 September, 2023
MD5 checksum: 6596FC091178D9F81667536187C38BE8
PDF: Analog Devices LTC3612 Monolithic Synchronous Step-Down Regulator Datasheet PDF

About this manual

The document introduces the LTC3612 as a high-efficiency step-down regulator capable of sourcing 3A or sinking 1.54A in TSSOP or QFN packages. It operates from an input range of 2.25V to 5.5V and features adjustable compensation for transient response optimization.

What's inside

Design Features
Burst Mode Operation
Power Supply Tracking
DDR Applications
Optional AVP Mode
Short-Circuit Protection

Frequently asked questions

What are the maximum source and sink currents for the LTC3612?

The device can source up to 3A or sink up to 1.54A.

What is the input voltage range for this regulator?

It operates from an input range of 2.25V to 5.5V.

What is the minimum adjustable output voltage?

The regulator provides an adjustable regulated output down to 0.6V.
