Linear Technology High Speed ADC Products Data Sheet

Introduces the series of high performance low power high speed ADC products including LTC2209, LTC2207, LTC2220-1, LTC2242-12, LTC2224, LTC2255, LTC2285, LTC1750

Brand: LINEAD
Category: Other Electronics
Document type: Product Leaflet
Language: English
Pages: 14
File format: PDF
File size: 867 KB
Published: 05 June, 2012
Updated: 30 September, 2023
MD5 checksum: 993839B82265C8F65FC59955B8560A29
PDF: Linear Technology High Speed ADC Products Data Sheet PDF

About this manual

This document introduces the portfolio of Linear Technology's high performance analog ICs, specifically focusing on their High Speed ADC Families. It covers several distinct product lines including the LTC2209/2207, LTCG2220-1/LTC2242-12, and LTC2224 series.

What's inside

Introduction
Lowest Power High Speed ADCs
LTC2209 ADC Family
LTC2207 ADC Family
LTC2220-1 and LTC2242-12 Families
LTC2224 ADC Family
CMOS vs LVDS Outputs

Specifications

Resolution (LTC2209)	16-Bit
Speed (LTC2209)	160Msps
Resolution (LTC2242-12)	12-Bit
Speed (LTC2242-12)	250Msps
Bandwidth (LTC2242-12)	1.2GHz

Frequently asked questions

What is the maximum sampling speed of the LTC2209 family?

The LTC2209 operates at a speed of 160Msps.

What are the applications for the LTC2242-12 family?

Applications include Cable Headend Systems, CATV Return Path Digitizer, and Radar.

What is the bandwidth of the LTC2242-12 family?

The LTC2242-12 family offers a full power bandwidth of 1.2GHz.
