C8051F062 16-bit ADCs, CAN, 64KB FLASH, 100-Pin MCU features
The C8051F062 is a 100‑pin TQFP microcontroller featuring two 16‑bit pipelined ADCs, two 12‑bit DACs, a CAN 2.0B controller with 32 message objects, and a built‑in temperature sensor. It operates from a 2.7 V to 3.6 V supply and supports up to 25 MHz system clock.
Key electrical characteristics include a supply current of 18 mA at 25 MHz CPU clock, 1 Msps ADC throughput, and various power‑saving modes. The device also offers multiple serial interfaces (SMBus/I²C, SPI, UART) and extensive on‑chip debugging features such as JTAG and boundary‑scan.
| Supply Voltage | 2.7 – 3.6 V |
|---|---|
| Supply Current (CPU Clock = 25 MHz) | 18 mA |
| Clock Frequency Range | DC 25 MHz |
| ADC Resolution | 16 bits |
| ADC Throughput Rate | 1 Msps |
| DAC Resolution | 12 bits |
| Temperature Range | -40 °C to +85 °C |
| Package | 100‑pin TQFP |
The device operates from 2.7 V up to 3.6 V.
The ADC provides 16‑bit resolution with a throughput of up to 1 Msps.
The CAN controller supports 32 message objects.
Yes, it has a built‑in temperature sensor with a typical accuracy of ±3 °C.
