Surface mount Zener Diodes MM3Z2V4 ... MM3Z100, 2.4V to 100V voltage range, 200mW power dissipation, SOT-323 plastic case, standard packaging is tape and reel
The MM3Z series are surface‑mount Zener diodes offered by Zener‑Diodes. They are supplied in a plastic SOD‑323 package and are intended for voltage regulation and protection applications.
Key specifications include a nominal Zener voltage range of 2.4 V to 100 V, a power dissipation rating of 200 mW, and a standard voltage tolerance of about 5% (E24 series). The devices operate over a wide temperature range and are packaged on reels for automated assembly.
| Power dissipation | 200 mW |
|---|---|
| Nominal Zener voltage range | 2.4 V – 100 V |
| Voltage tolerance | ~5% (E24 series) |
| Package type | SOD‑323 plastic case |
| Weight (approx.) | 0.005 g |
| Operating junction temperature | -50 °C – 125 °C |
The diodes are rated for a power dissipation of 200 mW.
The standard tolerance is about 5%, following the E24 series.
They are supplied in a plastic SOD‑323 case.
The nominal Zener voltage ranges from 2.4 V to 100 V.
