This operating manual provides step‑by‑step instructions for testing lead‑acid batteries with the GOLD‑PLUS Intelligent Battery Tester. It covers safety warnings, battery‑type identification, calibration positions, test procedures, and result interpretation.
The document also lists technical specifications such as operating voltage, supported battery types, accuracy, dimensions, and environmental limits, helping users ensure reliable measurements and proper maintenance of their batteries. This manual is written in German.
| Operating voltage | 5 V – 15 V DC |
|---|---|
| Battery types supported | Standby SLA (AGM), GEL cycle, flooded (KFZ) |
| Voltage accuracy | ±2 % of display value |
| Capacity accuracy | ±10 % for fully charged SLA |
| Dimensions | 210 mm × 110 mm × 41 mm |
| Weight | 0.6 kg |
Adjust the calibration screw to the position shown for each type: 12 o’clock for SLA, 9 o’clock for GEL, and 3 o’clock for flooded batteries.
A warning appears when a 6 V battery drops below 5.25 VDC or a 12 V battery drops below 12.0 VDC.
The simulated 20‑hour discharge test is completed in about 20 seconds, and a repeat test takes roughly 5 seconds.
