Arcolectric R13 Round Rocker Switches Handbook

R13 Round Rocker Switches 6A 250Vac PRODUCT DETAILS

Arcolectric R13 Round Rocker Switches Handbook - cover page
Brand
R13
Category
switch
Document type
Product Leaflet
Language
English
Pages
2
File format
PDF
File size
115 KB
Published
12 May, 2012
Updated
30 September, 2023
MD5 checksum
1635C2AEEF7B2A39C837D5C64BB557DE
PDF
Arcolectric R13 Round Rocker Switches Handbook PDF

About this manual

This handbook details the technical data, dimensions, and options for the R13 round rocker switches. It lists standard and special product variants, terminal functions, and mounting details, including panel cut‑out sizes and snap‑fit installation.

The switches are UL and CSA certified, available in single‑pole, double‑pole, and LED‑indicator configurations, and can be ordered with a range of body and rocker colours. Custom orders and special approvals are handled directly with the factory.

What's inside

  • Technical Data
  • Standard Products
  • Special Products
  • Terminal Functions
  • Product Details
  • Approvals
  • Sub‑panel Mounting
  • Protective Cover

Specifications

Current rating (single pole)6 A
Voltage rating250 Vac
Temperature rating85 °C
CertificationsUL and CSA
Maximum panel thickness for snap‑fit mounting3.0 mm

Frequently asked questions

What certification standards do the R13 switches meet?

The R13 switches are UL and CSA certified (UL file E67774(S) and CSA file LR45128).

What panel thickness can the switches be mounted in?

They can be snap‑fixed into panels up to 3.0 mm thick.

Do any R13 models include LED indicators?

Yes, certain models have LED indicators, such as a red LED on the paddle tip.
