Arcolectric Fuseholder Handbook

This document describes the features and characteristics of 5 x 20 mm fuseholders, including terminal types, dimensions, and installation methods.

Arcolectric Fuseholder Handbook - cover page
Brand
Fuseholders
Document type
Product Leaflet
Language
English
Pages
2
File format
PDF
File size
210 KB
Published
12 May, 2012
Updated
29 September, 2023
MD5 checksum
6FA4A4F463D1B451CFE1E8079AA0E993
PDF
Arcolectric Fuseholder Handbook PDF

About this manual

The Arcolectric Fuseholder Handbook provides detailed information on the various terminal body and cap panel hole options for fuseholders, including dimensions, panel thickness ranges, and recommended terminal types. It also lists maximum fuse ratings and dissipation limits for safe operation.

Additional sections describe connector materials, solder and push‑on terminal options, and technical data for different fuseholder types such as 0721‑P, 0722‑C and 0723‑C. Contact details for Arcolectric are included for further assistance.

What's inside

  • Terminal Body & Cap Panel Hole Options
  • Panel Hole Dimensions
  • Technical Data
  • Mouldings V2 (V0 option)
  • Connectors
  • Terminal Dimensions
  • For Switches
  • Type

Specifications

Maximum fuse rating6.3A 250Vac
Maximum dissipation wattage1.5W
Panel thickness range0.8‑4.5 mm
Current rating 20A125 Vac
Current rating 16A250 Vac
Solder terminal size2.8 mm

Frequently asked questions

What is the maximum fuse rating?

The maximum fuse rating is 6.3 A at 250 Vac.

What is the maximum dissipation wattage?

The maximum dissipation wattage is 1.5 W.

What panel thickness range is supported?

Panel thickness can range from 0.8 mm to 4.5 mm.
