This document is the technical data for MEDER's VMp-01 permanent magnet. It mainly provides product specifications, including magnet type, size, magnetic flux density, maximum operating temperature, etc.
The MEDER AlNiCo 500 7.5 × 27 magnet is a high‑performance permanent magnet made from an aluminium‑nickel‑cobalt alloy. It is supplied as a round bar with axial magnetisation and is intended for applications requiring stable magnetic properties over a wide temperature range.
The sheet provides the magnet's physical dimensions, magnetic performance data (energy product, remanence, coercivity), material density, and maximum operating temperature, all based on the manufacturer's information. Contact details for MEDER headquarters in Europe and the USA are also listed.
| Material | AlNiCo 500 |
|---|---|
| Energy product (B·H) max | 35–39.8 kJ/m³ |
| Remanence B | 1120–1240 mT |
| Coercivity H_es | 47.0–51.3 kA/m |
| Coercivity H_e | 48.0–51.7 kA/m |
| Maximum operating temperature | 450 °C |
| Part Number | 4003004006 |
The magnet can operate up to 450 °C.
The part number is 4003004006.
The remanence ranges from 1120 mT to 1240 mT.
