This document describes the long-term performance characteristics of the iX�ra SL-2780 model, including voltage, capacity, current, and other parameters.
The SL-2780 is a lithium‑ion battery with a nominal voltage of 3.6 V and a capacity of 19 Ah, intended for long‑term performance in a wide temperature range. It delivers a nominal current of 5 mA, a maximum continuous discharge of 200 mA and a pulse current capability of 450 mA.
Physical characteristics include an anode surface area of 45 cm², lithium content of 5 g, weight of 93 g and volume of 51 cm³. The data sheet also lists discharge‑curve graphs and important safety warnings for handling and disposal.
| Maximum continuous discharge current | 200 mA |
|---|---|
| Anode surface area | 45 cm² |
| Lithium content | 5 g |
| Weight | 93 g |
| Volume | 51 cm³ |
The battery can continuously discharge up to 200 mA.
Do not recharge, disassemble, heat above 100 °C, incinerate, or expose the contents to water.
