PT2128A is a high performance electronic fan controller from Princeton Technology Corp. It features high performance, low power consumption, DIP or SO package, optional independent light control, 90 seconds cycle/6 seconds/step(off step 3 seconds) rhythm wind pattern, four operation modes(ordinary, rhythm, ordinary sleep and rhythm sleep), memory startup mode, 2-3 seconds middle wind startup(mask option).
The PT2128A is a high‑performance CMOS remote fan controller IC that integrates speed control, timer, rhythm wind, sleep mode, swing‑head and light control in a single chip. It provides LED, buzzer, key inputs and built‑in remote decoding for compact fan designs.
The device is offered in various DIP and SO packages ranging from 16 to 24 pins, supports up to three swing‑head or light outputs, and includes four operation modes (ordinary, rhythm, ordinary‑sleep, rhythm‑sleep). Application circuits and pin configurations are provided for easy PCB layout.
| Technology | CMOS |
|---|---|
| Power consumption | Low |
| Package options | DIP or SO, 16‑24 pins |
| Swing‑head / Light outputs | Up to 3 dependent/independent |
| Operation modes | Ordinary, Rhythm, Ordinary Sleep, Rhythm Sleep |
PT2128A is available in DIP or SO packages with 16, 18, 20, 22, or 24 pins.
It can control up to three dependent or independent swing‑head or light outputs, with optional independent light control.
The IC supports four modes: ordinary, rhythm, ordinary sleep, and rhythm sleep.
Yes, it has built‑in remote control decoding circuitry with a mask‑option custom code.
