The E1702 is a 17‑inch (432 mm diagonal) TFT‑LCD monitor that supports resolutions up to 1280 × 1024, offers 16.2 M colors, 300 cd/m brightness, and a typical 8 ms response time. It includes D‑Sub (optional DVI‑D) video input, audio jack, and a low‑power AC adapter.
This manual covers package contents, quick installation instructions, detailed specifications, safety precautions, environmental certifications (TCO'99, ENERGY STAR), and regulatory compliance statements (FCC, CE, Canadian). It also provides troubleshooting guidance via the included CD‑ROM.
| Screen Size | 17 inch (Diagonal 432 mm) |
|---|---|
| Resolution | 1280 × 1024 (SXGA) |
| Display Colors | 16.2 M colors |
| Brightness | 300 cd/m |
| Contrast Ratio | 400:1 |
| Response Time | Typical 8 ms (Tr 2 ms + Tf 6 ms) |
| Viewing Angle | Horizontal 150°, Vertical 130° |
| Pixel Pitch | 0.264 mm (H) × 0.264 mm (V) |
| Bandwidth | 135 MHz |
| Input Connector | 15‑pin D‑Sub (optional DVI‑D) |
| Power Consumption (Operating) | <45 W |
| Power Consumption (Stand‑by) | <2 W |
| Operating Temperature | 5 °C – 35 °C (working), –20 °C – 55 °C (storage) |
| Humidity | 20 % – 80 % (working), 20 % – 85 % (storage) |
| Dimensions (W × H × D) | 378 mm × 404 mm × 190 mm |
Use only the original accessories, ensure the correct power supply is used, do not let children operate the monitor alone, and read the user manual for additional safety information.
