Freescale TWR-MPC8309 Quick Start Guide

This document is a quick start guide for the TWR-MPC8309 PowerQUICC processor, which introduces the features and characteristics of the processor, including industrial connectivity and protocol offload engine.


Freescale TWR-MPC8309 Quick Start Guide - cover page
Brand
TWR-MPC8309
Document type
Quick Start Guide
Language
English
Pages
8
File format
PDF
File size
1.7 MB
Published
09 May, 2012
Updated
30 September, 2023
MD5 checksum
4DA4C2F07AD8F0DB9910420E8B5A654F

About this manual

The TWR-MPC8309 is a PowerQUICC processor module that provides industrial connectivity and a protocol off‑load engine. It can be used as a stand‑alone single‑board computer, an elevator‑connected system‑on‑module, or as part of Freescale’s modular Tower System for rapid prototyping.

The guide walks you through connecting a display, power source, USB and Ethernet cables, configuring the virtual COM port, and accessing the boot and diagnostic menus. It also describes the built‑in demo that runs on power‑up and how to modify it, as well as switch settings for UART, USB, RS485 and JTAG interfaces.

What's inside

  • Get to Know the TWR-MPC8309
  • Step‑by‑Step Installation Instructions
  • Connecting Cables
  • Debugger Interface Connections
  • Configuration Switch Settings
  • Boot Configuration and Diagnostic Menus
  • Informational Demo

Specifications

ProcessorPowerQUICC
USB2 High‑Speed portAvailable
USB2 Full‑Speed portConsole and power
Ethernet portsDual 10/100 Ethernet
RS485 portsDual RS485 with loopback cable
JTAG/COP headerDebug interface
Boot sourceOn‑board NOR flash (default)
Serial console settings115200 bps, 8N1, no flow control

Frequently asked questions

How do I connect the TWR-MPC8309 to a host computer?

Connect the USB2 Full‑Speed port to the host using the supplied USB cable, then install the TWR‑MPC8309 VirtualCOM driver and configure the terminal at 115200 bps, 8N1, no parity, no flow control.

How can I change the boot configuration of the board?

While the board is booting, hold any key on the host computer; the boot configuration menu appears in the console, allowing you to select different boot sources and options.

How are the RS485 ports connected for a loopback test?

Use the included RS485 loopback cable, aligning pin 1 (marked with an arrow) on the cable connector to pin 1 on each RS485 header.
