The DP Series Power Inductors provide an excellent, low cost alternative to conventional chokes or inductors. Used in EMI filtering and energy storage, these compact, low radiation inductors are extremely effective in controlling AC output ripple of Switch Mode Power Supplies.
The DP Series offers a broad range of inductance values and current ratings in a low‑cost, no‑radiation design. Features include hot‑solder, pre‑tinned leads for easy PCB mounting and an operating frequency up to 100 kHz. The inductors are manufactured in ISO‑9001, TS‑16949 and ISO‑14001 certified facilities and are fully RoHS compliant.
These inductors are intended for switching power supplies, EMI/RFI filtering and output choke applications. Various mounting styles (Open, Clip, Base, Vertical, Flat) are available, and the series can be ordered using the DP‑O‑0‑470‑WH key. Technical data such as inductance, DCR, energy rating and dimensions are provided for each part number.
| Operating frequency | up to 100 kHz |
|---|---|
| Test voltage between windings | 500 Vrms |
| Operating temperature range | -40 °C to +125 °C |
| Climatic category | IEC68-1 40/125/56 |
| RoHS compliance | Fully compliant |
The inductors can operate up to 100 kHz.
Yes, they are fully RoHS compliant.
Open, Clip, Base, Vertical and Flat mounting styles are offered.
They are used in switching power supplies, EMI/RFI filtering and output chokes.
