The EVD Series subminiature‑D connectors are designed for military and severe industrial environmental applications, offering removable contacts, high humidity resistance, and protection against immersion in water or organic liquids. The connectors comply with MIL‑C‑24308 and MIL‑C‑39029 standards and feature precision‑machined brass or high‑tensile alloy contacts with gold or nickel plating.
Technical characteristics cover materials and finishes, electrical and mechanical performance, and environmental testing. Ordering information is provided through a step‑by‑step code numbering system that specifies series, shell options, gender, contact type, mounting style, and accessories.
| Contact Current | 7.5 A (nominal) |
|---|---|
| Initial Contact Resistance | 0.005 Ω max |
| Plating Thickness | 1.25 µm gold over copper |
| Working Voltage | 300 V rms |
| Temperature Range | ‑55 °C to +125 °C |
| Contact Retention | 9 lb (40 N) |
The connectors are rated for a nominal contact current of 7.5 A.
The initial contact resistance is limited to 0.005 Ω maximum.
They are specified for operation from –55 °C up to +125 °C.
The connectors are rated for a working voltage of 300 V rms.
