This document provides instructions on repairing the Kodak Instamatic M80 projector and variations in other M-series projectors. It also includes tips on repairing the Kodak Moviedeck projectors.
This manual provides detailed instructions for disassembly, repair, and reassembly of Kodak Instamatic M‑series projectors. It includes flow charts, tool recommendations, inspection procedures, and wiring pictorials, with special notes for variations among the M70, M80, M85, M90, and M95 models.
Safety precautions, troubleshooting tips, lubrication guidelines, and specifications for lamps, motors, and film speeds are covered, helping technicians restore proper operation to these vintage projectors.
| Projection lamp voltage (M80, M70, M85) | 120 V |
|---|---|
| Projection lamp voltage (M90, M95) | 21 V |
| Projection lamp wattage | 150 W |
| Motor supply voltage | 110‑125 V AC, 60 Hz |
| Running speed (M85) | 18 fps only |
The M80 uses a 120 V projection lamp.
The M80 uses a 120 V lamp, while the M90 uses a 21 V lamp that requires a step‑down transformer.
Unplug the projector from the wall outlet before removing the bottom cover.
