The product is a high reliability DC-DC converter with an output power of up to 30W, three fully isolated outputs, wide input voltage range, internal EMI filter, meeting MIL-STD-461C and MIL-STD-461D conducted emission requirements
The DVST2800T series provides high‑reliability DC‑DC conversion with internal EMI filtering, meeting MIL‑STD‑461C and MIL‑STD‑461D for conducted emissions. It operates over a wide temperature range, features a magnetic feedback circuit that is radiation‑immune, and offers three fully isolated low‑noise outputs for flexible system design.
Key specifications include a continuous input voltage range of 15‑50 V, a transient rating of 80 V (1 s), up to 30 W output power, and operation from –55 °C to +100 °C. The series is available in a low‑profile (0.380 in) package, with optional military environmental screening and custom versions on request.
| Input Voltage (Continuous) | 15 to 50 V |
|---|---|
| Input Voltage (Transient, 1 s) | 80 V |
| Maximum Output Power | 30 W |
| Number of Isolated Outputs | Three |
| Operating Case Temperature | -55 °C to +100 °C |
| Storage Temperature | -55 °C to +125 °C |
| Maximum Weight | 100 g |
| Package Height | 0.380 in |
The maximum continuous input voltage is 50 V.
It provides three fully isolated outputs.
The converter operates from –55 °C to +100 °C.
The device can deliver up to 30 W of output power.
