This document is about the specifications of the MC16021E series products
The MC16021E series is a liquid crystal display module offered by Verbouquet International. It supports 16 characters per line on two lines and features various LCD types (STN, FSTN, etc.) with selectable backlight and viewing angles.
Key specifications include a module size of 84 mm × 44 mm, a logic power supply voltage range of 0‑6 V, operating temperature from –20 °C to 70 °C, and detailed optical characteristics such as contrast and response time. The document also lists mechanical dimensions, pin connections, and recommended resistor values for the LCD driving circuit.
| Number of characters | 16 characters per line, 2 lines |
|---|---|
| Module size | 84.0 mm width × 44.0 mm height (max) |
| Effective display area | 64.5 mm width × 16.0 mm height |
| Character size | 2.96 mm width × 4.86 mm height |
| Dot size | 0.56 mm width × 0.66 mm height |
| Logic power‑supply voltage range | 0 V to 6.0 V |
| Normal operating temperature | 0 °C to 50 °C |
| Wide operating temperature | -20 °C to 70 °C |
The module measures 84.0 mm wide by 44.0 mm high (maximum dimensions).
It can display 16 characters per line on two lines.
The normal range is 0 °C to 50 °C, and the wide range is –20 °C to 70 °C.
The logic supply should be between 0 V and 6.0 V.
