10025HR-04 to 10025HR-25 is a series of open-end wire terminal blocks.
The 10025HR series FPC/FFC connectors from Yeonho are designed for 0.30 ± 0.03 mm pitch applications and are available in a range of lengths from 4.0 mm to 23.7 mm. They feature a PA6T housing, phosphor‑bronze contacts with tin/gold plating, and are UL94‑V0 compliant.
Key specifications include a 50 V AC/DC voltage rating, 1 A current rating, operating temperature from –25 °C to +85 °C, contact resistance up to 30 mΩ, and a withstanding voltage of 500 V AC for 1 minute. The connectors are suitable for PCB traces of 0.8 – 1.6 mm and FPC/FFC cables of 0.30 ± 0.03 mm.
| Voltage Rating | 50 V AC/DC |
|---|---|
| Current Rating | 1 A AC/DC |
| Operating Temperature | -25 °C to +85 °C |
| Contact Resistance | ≤ 30 mΩ |
| Withstanding Voltage | 500 V AC for 1 min |
| Insulation Resistance | ≥ 100 MΩ |
| Applicable PCB | 0.8 – 1.6 mm |
| Applicable FPC/FFC | 0.30 ± 0.03 mm |
| Solder Height | 0.15 mm |
The connectors are rated for 50 V AC/DC.
They operate from –25 °C up to +85 °C.
The contact resistance is limited to 30 mΩ maximum.
