This is a user manual for an air conditioner
This manual provides step‑by‑step instructions for installing the Electra GREEN series split‑type air‑conditioners (models 09 C/F, 12 C/F, 18 C/F and 22 C/F). It includes details on mounting the indoor and outdoor units, connecting refrigerant lines, installing the drainage hose and performing the required vacuum purge.
The guide also describes the remote‑control functions, available operating modes (cool, heat, fan, dry, auto, sleep, etc.) and lists the main technical specifications such as dimensions, weight and optional features like washable PP filters and LCD display. This manual is written in Spanish.
| Indoor unit dimensions (L×W×H, mm) | 750×250×190 |
|---|---|
| Net weight (outdoor), kg | 26 |
| Front panel LCD display | Yes |
| Washable PP filter | Yes |
Press and hold any remote‑control button for 2 seconds; the support light will turn on, indicating the remote is in programming mode.
