Smart Tweezers™ is a handheld LCR meter of a new concept. It pro- vides a perfect solution for testing and identification of Surface Mount Devices as well as troubleshooting of complex electronic systems. Its unique mechanical and electronic design combines a pair of precise gold-plated tweezers and a digital LCR meter in compact, lightweight, battery powered instrument. The probe is able to measure resistance, capacitance, inductance and voltage with high accuracy and automatic component recognition.
The Smart Tweezers™ combines a pair of precise gold‑plated tweezers with a digital LCR meter in a compact, battery‑powered instrument. It is designed for one‑hand operation to test and identify surface‑mount devices (SMD) as well as conventional components with short leads. The built‑in high‑precision probe automatically determines the component type and selects the appropriate measurement range, displaying the result on the primary display.
The device offers dual‑mode voltmeter functionality (DC in AUTO mode, AC waveform in TRACE mode), a continuity detector with audible beeper, and replaceable steel tips for reliable contact. Physical specifications include a 0 °C to +55 °C operating temperature range, three LR44 batteries (alkaline or zinc‑air) providing up to 240 hours of continuous use, dimensions of 14.0 × 2.5 × 3.0 cm and a weight of 53 g. Detailed measurement ranges cover resistance (0.1 Ω – 5 MΩ), capacitance (0 pF – 4999 pF), inductance (1 µH – 499 mH) and voltage up to 8 V.
| DC Voltage Range | 0 to 800 mV (up to 8 V manual) |
|---|
It automatically determines the component type (resistance, capacitance, inductance) and selects the proper range for high‑accuracy measurements.
Yes, it has a dual‑mode voltmeter function: in AUTO mode it measures DC voltage, and in TRACE mode it displays the AC waveform.
