The inDART-STX is an entry‑level in‑circuit debugger/programmer for STMicroelectronics ST7‑based systems. It connects to a host PC via USB and uses a standard 10‑pin ST7 ISP connector to program and debug the FLASH memory of ST72F family microcontrollers. The device includes a 10‑pin probe, a demo board for evaluation, and integrates with the STVD7 Integrated Development Environment.
The manual covers hardware specifications, installation steps, software configuration, programming capabilities, and a troubleshooting guide. An appendix lists electrical and physical specifications such as operating voltage, power consumption, dimensions, and environmental limits.
| Operating Voltage | 5 V DC (provided by the USB connection) |
|---|---|
| Power Consumption | 150 mA (max) |
| OSC Signal Characteristics | 4 MHz or 8 MHz, 50% duty cycle |
| Dimensions | 95 x 55 x 15 mm |
| Weight | 25 g |
| Operating Temperature | 0 °C to 50 °C |
| Storage Temperature | -20 °C to 70 °C |
| Humidity | 90% (without condensation) |
The inDART‑STX is connected to the host PC through a USB port.
It uses the standard 10‑pin ST7 ISP connector to program and emulate the target device.
The device consumes up to 150 mA of current.
It operates from a 5 V DC supply provided by the USB connection.
