The document introduces the features and characteristics of a display device, including bandwidth, number of channels, sample rate, record length, advanced trigger, etc. It also provides multiple interface options and optional accessories.
The GW Instek GDS-2000 series includes six digital storage oscilloscopes (GDS-2062, GDS-2064, GDS-2102, GDS-2104, GDS-2202, GDS-2204) offering 1 GSa/s real‑time sampling, up to 25 k‑point record length, and bandwidths of 60 MHz, 100 MHz or 200 MHz. The instruments feature a 5.6‑inch TFT color LCD, USB host/device, RS‑232C, optional GPIB, and battery operation for field use.
The manual describes key functions such as advanced triggering, auto‑measurement, FFT, Go/NoGo testing, remote control, and data transfer. It also provides ordering information, optional accessories, and detailed specifications for each model.
| Sample Rate | 1 GSa/s real‑time (25 GSa/s equivalent) |
|---|---|
| Record Length | 25 k points |
| Display | 5.6‑inch TFT color LCD, 234 × 320 pixels |
| Input Impedance | 1 MΩ ± 2 % (≈16 pF) |
| Sensitivity | 2 mV/div – 5 V/div |
| Rise Time | 5.8 ns (60 MHz), 3.5 ns (100 MHz), 1.75 ns (200 MHz) |
| Maximum Input Voltage | 300 V (DC + AC peak), CAT II |
| Weight | ≈4.3 kg |
The GDS‑2064 model provides four input channels.
The GDS‑2204 offers a 200 MHz bandwidth.
