This manual introduces VERBAR's differential‑pressure flow meters, describing how the probe creates a high‑pressure zone at the stagnation point and a low‑pressure zone downstream, allowing flow rate to be derived from the pressure difference. It also details the bullet‑shaped probe design, integrated one‑piece construction, and the placement of low‑pressure ports to prevent blockage and ensure stable signals.
The document provides performance data (accuracy, pressure and temperature ranges), compares VERBAR probes with traditional orifice plates, and lists various product families (commercial, industrial, high‑temperature/high‑pressure, online) with their connection options, pipe‑size limits and installation instructions. This manual is written in Chinese.
| Measurement accuracy | ±19 % |
|---|---|
| Repeatability | ±0.19 % |
| Applicable pressure range | 0 ~ 25 MPa |
| Applicable temperature range | -180 ~ 540 °C |
| Pipe diameter range | 38 mm ~ 6000 mm |
| Range ratio | >10 : 1 |
The measurement accuracy is ±19 %.
They are suitable for pressures from 0 to 25 MPa.
They can be used from –180 °C up to 540 °C.
VERBAR probes cover pipe diameters from 38 mm to 6000 mm.
