HZIE-C43 series current sensor is a measurement module that converts the measured current into a follow-up voltage signal using the Hall effect and open-loop measurement principle. The primary and secondary sides are highly insulated. It has the characteristics of high precision, high linearity, high integration, small volume, simple structure, long-term stable operation and adaptation to various working environments.
The HZIE-C43 series current sensor from Passion Technology is designed for high‑precision current measurement in industrial applications such as power, oil, chemical, railway and building automation. It offers high accuracy, strong anti‑interference capability, compact size and easy installation.
The manual includes product introduction, technical specifications, mechanical dimensions, electrical connection details, output characteristics, safety precautions and installation instructions, helping users correctly integrate the sensor into their systems. This manual is written in Japanese.
| Rated Current Range | 500‑2000 A |
|---|---|
| Bandwidth | DC‑10 kHz |
The sensor can measure currents from 500 A up to 2000 A.
