This document is a product manual that provides instructions and guidelines for the installation, use, maintenance, and troubleshooting of a washing machine. It also includes laundry guidelines, operating procedures, and maintenance tips.
This manual provides detailed safety precautions, installation steps, and operating instructions for the washing machine. It includes guidance on unpacking, positioning, water inlet and drainage connections, as well as control panel functions.
Additional sections cover technical specifications, environmental tips, maintenance procedures, and fault diagnosis with error codes and remedies. This manual is written in Chinese.
| Dimensions (H×W×D) | 85 cm × 60 cm × 63 cm |
|---|---|
| Maximum Rated Capacity (Cotton/Linen) | 7 kg |
| Maximum Rated Capacity (Synthetic) | 3 kg |
| Maximum Rated Capacity (Delicate) | 3 kg |
| Maximum Rated Capacity (Wool/Hand‑wash) | 2 kg |
| Maximum Spin Speed | 1200 rpm |
| Power Supply | AC 220 V / 50 Hz |
| Total Input Power | 2000 W |
| Rated Current | 10 A |
| Water Pressure (min‑max) | 50 kPa – 800 kPa |
| Noise (Wash) | 52.8 dB |
| Noise (Spin) | 61.8 dB |
| Energy Efficiency Class | 1 |
| Energy Consumption per Cycle | 1.26 kWh |
| Water Consumption per Cycle | 70 L |
| Wash‑to‑Water Ratio | 1.03 |
Use the emergency drain procedure: unplug the machine, close the water tap, open the drain pump cover, place a container under the emergency drain pipe, remove the pipe plug, and let the water flow out. Repeat until all water is removed, then reinstall the plug and close the pump cover.
Disconnect power and water, drain all water from the machine using the emergency drain pipe, then reinstall the water inlet and drain pipes after the water has been removed. Ensure the ambient temperature stays above 0 °C before using the machine again.
Error code E10 relates to an inlet water problem, such as a closed tap, a kinked or blocked inlet hose, or a clogged inlet filter.
No, the machine is designed for household use only and should not be used for commercial, industrial, or other non‑residential applications.
