The RENLE RNL6000 is an intelligent electric machine protection implement designed for comprehensive monitoring and control of motor and drive systems. It features a 32‑bit DSP (TMS320F28034) and a user‑friendly LCD interface that displays fault, current, voltage, and temperature data in real time.
The device supports multiple communication protocols, including RS485 (Modbus‑RTU), Profibus‑DP, CAN, and DeviceNet, allowing integration into various automation networks. It offers a wide range of protection functions such as over‑current, undervoltage, phase‑imbalance, residual‑current, power‑factor, and startup‑timeout protection, as well as configurable settings for different application needs. This manual is written in Chinese.
| DSP Chip | TMS320F28034 |
|---|---|
| Communication Interfaces | RS485 (Modbus‑RTU), Profibus‑DP, CAN, DeviceNet |
| LCD Display | Yes, with Chinese language interface |
| Model Variants | RNL6000‑100A/HL‑M1‑GMR, RNL6000‑50A/HL‑MD‑GMSR |
The RNL6000 supports RS485 with Modbus‑RTU, Profibus‑DP, CAN, and DeviceNet interfaces.
The device uses a 32‑bit TMS320F28034 DSP.
