This document provides information on the installation precautions, electrode and electrical wiring, front panel operation, measurement mode, parameter setting mode, calibration mode, error messages, and maintenance of the PC3200 microcontroller.
This manual covers the specifications, installation steps, electrode wiring, measurement modes and calibration procedures for the Philips PC3200 pH/ORP meter. It includes detailed wiring diagrams, alarm settings, power supply information and troubleshooting guidance.
The document also provides technical data such as measurement ranges, resolution, accuracy, temperature compensation, dimensions and weight, as well as safety precautions and recommended maintenance practices. This manual is written in Chinese.
| Weight | 1.9 kg |
|---|
Use the pH calibration mode described in section 7.1, which outlines the step‑by‑step calibration procedure.
Follow the electrode wiring reference diagrams in section 3.4, which specify the connections for GND, REF, GLASS and TP terminals.
