This manual provides step‑by‑step instructions for installing the car multimedia player, wiring the unit, and securing it to the vehicle. It includes a parts list, mounting guidelines, and safety warnings for proper electrical connections.
The guide also describes all operating modes—radio, DVD/VCD, CD/MP3, USB, SD, iPod, Bluetooth, DTV, AUX‑in, and rear‑view camera—detailing touch‑screen zones, remote‑control keys, and menu navigation. Bluetooth pairing, call handling, and screen‑off power‑saving features are explained in dedicated sections.
| Power Requirements | 14.4V DC |
|---|---|
| Load Impedance | 40 Ω |
| Max Power Output | 60 W ×4 |
| Tone Controls | +7 dB (Bass 100 Hz, Treble 10 kHz) |
| Dimensions | ≈178 mm × 170 mm × 100 mm (D × W × H) |
| Weight | ≈3 kg |
| Frequency Response | 30 Hz – 15 kHz |
Press the "F/M" button on the screen to enter power‑saving mode; the screen turns off while audio continues, and touching any screen area or pressing any panel button exits the mode.
