104-1542CLD is a full-featured embedded industrial computer motherboard developed by EVCO Intelligent Technology Co., Ltd. This motherboard is based on AMD Geode chip, with 32M/64M/128Mbytes SDRAM on board, CRT/LCD interface, DOC socket, IDE interface, two serial ports, built-in watchdog timer and PC/104 expansion interface.
This manual introduces the EVOC 104-1542CLD PC/104 industrial computer motherboard, a compact, low‑power board based on an AMD Geode GX1 processor. It details the hardware features, supported interfaces, and environmental specifications for embedded system applications.
The document covers safety precautions, a checklist of accessories, step‑by‑step installation instructions, BIOS configuration, watchdog programming, I/O address mapping, IRQ assignments, and boot device order. Appendices provide programming examples and reference tables for developers and system integrators. This manual is written in Chinese.
