The BR43-005/7 automatic winding machine is designed for winding high‑voltage coils of small‑ and medium‑size transformers. It consists of a main body, spindle housing, tailstock, wire‑feeding mechanism, foot switch, unwinding frame, round‑wire feeding frame, inter‑layer insulation feeding device, and an electrical control cabinet. The wire‑feeding mechanism includes a tension‑adjustable guide rail and rollers to ensure stable tension.
The manual covers the machine’s purpose and functions, technical specifications, installation steps, control‑panel operation, adjustment options (tension, guide‑roller width, gear selection), and routine maintenance procedures such as lubrication and cleaning of guide rails and spindle bearings. This manual is written in Chinese.
| Spindle center height | 950 mm |
|---|---|
| Maximum load | 500 kg |
The guide rails and ball screws should be cleaned and lubricated once, using clean grease without impurities.
