This manual provides detailed instructions for installing, operating, and maintaining the YS1200 FM(T) water heater. It covers safety devices, temperature adjustment, and troubleshooting procedures.
The document also includes technical specifications such as dimensions, power consumption, and required water flow, as well as regular inspection and cleaning guidelines to ensure safe and reliable performance. This manual is written in Chinese.
| Input Voltage | AC220V 50Hz |
|---|---|
| Rated Power Consumption | 46 W (operating) |
| Weight | 13.5 kg |
| Minimum Water Flow | 2.5 L/min |
| Temperature Adjustment Range | 35°C‑49°C |
| Fuel Consumption (LPG) | 25.0 kW / 1.80 kg/hr |
Use the temperature adjuster on the main controller to set the water temperature between 35 °C and 49 °C.
The heater requires a minimum water flow of 2.5 L/min to operate safely.
The unit includes over‑temperature lock, over‑pressure protection, low‑flow shutdown, and over‑current protection among other safety features.
The heater consumes 46 W when operating.
