This document introduces the new AS series closed loop control stepper motor combination products developed by ORIENTAL MOTOR company. This product has good performance, including the ability to not lose steps under severe load changes and rapid acceleration, high response, and high reliability.
The Oriental Motor AS series catalog presents a range of 5‑phase and 2‑phase stepper motors, their variants, and compatible drive units. It includes system configurations, mechanical drawings, connection details, and recommended accessories.
Key features include closed‑loop control options, high resolution pulse settings, various reduction gear options (TH, PL, PN, etc.), and compliance with UL/CSA/CE safety standards. The document also provides wiring diagrams, end‑position signals and alarm outputs for integration with controllers. This manual is written in Chinese.
| Input voltage (single‑phase) | 100V‑115V |
|---|---|
| Input voltage (single‑phase, high) | 200V‑230V |
| Input voltage (three‑phase) | 200V‑230V |
| Pulse resolution (1000P/R) | 0.36° per pulse |
| Auxiliary power for brake | DC24V±5% |
The motor provides a resolution of 0.36° per pulse when set to 1000 pulses per revolution.
The motors can be powered with single‑phase 100V‑115V, single‑phase 200V‑230V, or three‑phase 200V‑230V supplies.
