This document describes the features and performance list of the Pentium II/III processor and AGP, as well as the hardware and software specifications and environmental requirements. The document also provides detailed steps for hardware installation and BIOS configuration.
This manual covers everything needed to install and configure the 6BNZ motherboard, a Pentium II/III/Celeron‑based PC/AT compatible board with AGP, PCI, and ISA buses. It includes an introduction, key features, a performance list, and detailed hardware specifications.
The guide walks users through hardware installation steps such as unpacking, motherboard layout, jumper settings, CPU speed setup, DRAM installation, and peripheral connections. It also explains BIOS configuration, power management, and troubleshooting tips. This manual is written in Chinese.
| Supported CPUs | Pentium II / III / Celeron 233‑633 MHz |
|---|---|
| Chipset | Intel 440BX |
| Graphics | Built‑in ATi 3D RAGE PRO with 2 M SGRAM |
| Audio | Built‑in YAMAHA 715E audio chip |
| LAN | Built‑in Intel SB82558B LAN chip |
| USB Ports | 2 USB ports |
| Form Factor | NLX, 4‑layer PCB |
The board supports Intel Pentium II, Pentium III, and Celeron processors ranging from 233 MHz to 633 MHz.
CPU speed is set via DIP switches on the board; the default bus speed is 66/100 MHz, and you can select a CPU speed between 233 MHz and 633 MHz using the appropriate switch settings.
It includes an ATi 3D RAGE PRO graphics chip with 2 M high‑speed SGRAM, compliant with the AGP 1.0 interface.
