This manual introduces the features and characteristics of the 6BXD motherboard, including hardware installation and BIOS configuration.
This manual introduces the 6BXD motherboard, a dual‑Pentium II processor‑based AT/PC compatible board featuring Intel 440BX chipset, AGP, PCI, and ISA buses. It outlines key features such as dual‑processor support, up to 1 GB of EDO/SDRAM memory, multiple I/O ports, and integrated power‑management functions.
The document covers hardware installation steps, BIOS setup procedures, CPU speed configuration via DIP switches, and detailed specifications of the CPU, memory, I/O slots, and power requirements. It also includes safety warnings and troubleshooting tips for components like the CMOS battery and speaker connector. This manual is written in Chinese.
| Supported CPUs | Dual Pentium II processors 200–633 MHz |
|---|---|
| Chipset | Intel 440BX |
| AGP Bus Speed | 66 MHz (133 MHz 2× mode) |
| USB Ports | 2 USB ports |
| PCI Slots | 5 PCI slots (33 MHz) |
| ISA Slots | 2 ISA slots (8 MHz, 16‑bit) |
The board supports dual Intel Pentium II processors with clock speeds from 200 MHz up to 633 MHz.
The motherboard provides two USB ports.
