GA-6IEM(L) Series Socket 370 Processor Motherboard USER’S MANUAL
The GA-6IEM Series is a Micro ATX motherboard that supports Socket 370 processors such as Pentium III and Celeron Tualatin. It provides a range of I/O options, including AGP, PCI, IDE, USB, and audio connectors.
This manual guides users through hardware installation, BIOS configuration, power‑management settings, and includes a technical reference with block diagrams and specifications. Safety precautions for handling the board and static‑discharge protection are also detailed.
| Form Factor | Micro ATX 24.4 cm x 20.2 cm |
|---|---|
| CPU Socket | Socket 370 (supports Pentium III Tualatin, Coppermine, Celeron Tualatin) |
| System Bus Frequency | 66 MHz / 100 MHz / 133 MHz |
| Memory Slots | 2 × 168‑pin DIMM, up to 512 MB SDRAM |
| Chipset | Intel 82815 B‑step HOST/AGP/Controller |
| AGP Slot | 1 |
| PCI Slots | 3 (33 MHz, PCI 2.2 compliant) |
| IDE Ports | 2 IDE bus master (DMA33/ATA66/ATA100) |
| USB Ports | 4 (rear x2, front x2) |
| Audio Header | 1 Front Audio Header |
Unplug the computer, use a grounded wrist strap, and handle components by the edges or on a grounded antistatic pad.
The board uses the AMIBIOS Simple Setup Utility version 1.24b from American Megatrends.
It is a Micro ATX board measuring 24.4 cm by 20.2 cm.
The motherboard provides four USB ports, two on the rear and two on the front.
