Corning Hotware laboratory hot plates (PC‑200, PC‑400, PC‑600 series) are designed for safe indoor use, offering precise heating and optional stirring functions. The units feature a microprocessor‑controlled heating element, a Pyroceram® top, and optional temperature controller accessories.
This manual covers general information, safety warnings, operating controls for heating and stirring, inspection and preventive maintenance procedures, technical specifications, optional accessories, and warranty details. It also provides service and repair guidance for qualified technicians.
| Dimensions (PC‑200) | 44 H × 5.8 W × 7.3 D inches |
|---|---|
| Supply voltage tolerance | ±10 % of nominal voltage |
| Pollution Degree | 2 (IEC 664) |
The Hot Top Indicator light illuminates when the top plate temperature exceeds 140 °F (60 °C).
Position each unit at least 12 inches from walls, 48 inches from the ceiling, and maintain a 12‑inch gap between hot plates.
A digital temperature controller (part 400188) can be installed on PC‑400 and PC‑600 series units to control temperatures between 77 °F and 390 °F.
