This document is the user manual of ASUS M2N68-LA motherboard, which introduces the motherboard's various functions and features, including CPU socket, memory slots, graphics card slots, audio interfaces, network interfaces, USB interfaces, etc.
This manual describes the EP-8RDAEI motherboard's hardware features, including the nVidia nForce2 400 chipset, Winbond W83627HF TO monitoring chip, Realtek ALC655 AC97 audio, and Realtek RTL8201BL LAN PHY. It lists the supported CPU socket, memory types, and expansion slots.
The document also covers jumper configurations, detailed connector pinouts for power, USB, audio, and IDE interfaces, and provides guidance for installing memory modules up to 2 GB of DDR SDRAM. This manual is written in Japanese.
| CPU socket | Socket A |
|---|---|
| Chipset | nVidia nForce2 400 |
| Audio codec | Realtek ALC655 AC97 |
| LAN PHY | Realtek RTL8201BL |
| Maximum memory | 2 GB DDR SDRAM |
| Memory slots | 2 × 184‑pin DDR DIMM |
| Power connectors | ATX 20‑pin and ATX12V 4‑pin |
| PCI slots | 3 × 32‑bit PCI |
| AGP slot | 1 × 1.3 V AGP |
| USB ports | 2 × USB 2.0 |
It uses a Socket A CPU socket.
The board supports up to 2 GB of DDR SDRAM.
The integrated audio chip is Realtek ALC655 AC97.
The LAN controller uses a Realtek RTL8201BL PHY.
